2N2222 NPN Metal Transistor 75V 800mA TO-18

2N2222 is a semiconductor device used to amplify or switch electronic signals and electrical power. It is composed of semiconductor material usually with at least three terminals for connection to an external circuit. A voltage or current applied to one pair of the transistor’s terminals controls the current through another pair of terminals. Because the controlled (output) power can be higher than the controlling (input) power, a transistor can amplify a signal. Today, some transistors are packaged individually, but many more are found embedded in integrated circuits.

Features:-

• Metal Can Package
• Advanced process technology
• Low error voltage
• Fast switching speed
• Full-voltage operation
• High power and current handling capability

Features / Technical Specifications:

• Package Type: TO-18
• Transistor Type: NPN
• Max Collector Current(IC): 800mA
• Max Collector-Emitter Voltage (VCE): 40V
• Max Collector-Base Voltage (VCB): 75V
• Max Emitter-Base Voltage (VEB): 6V
• Max Collector Dissipation (Pc): 500 Milliwatt
• Max Transition Frequency (fT): 300 MHz
• Minimum & Maximum DC Current Gain (hFE): 100 to 300
• Max Storage, Operating & Junction temperature range: -65 to 200 Centigrade

Applications:

• FM Radios
• FM Senders
• Audio premamplifiers
• Audio amplifiers
• Normal and high speed switching

2N2222 Datasheet
