Technical Specifications
| Physical | |
| Case/Package | DIP |
| Mount | Through Hole |
| Number of Pins | 16 |
| Technical | |
| High Level Output Current | 6.8 mA |
| Independent Circuits | 1 |
| Logic Function | Decoder |
| Low Level Output Current | 6.8 mA |
| Max Operating Temperature | 125 °C |
| Max Output Current | 2.4 mA |
| Max Supply Voltage | 20 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 3 V |
| Number of Bits | 3 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Gates | 1 |
| Number of Input Lines | 4 |
| Number of Inputs | 4 |
| Number of Output Lines | 10 |
| Number of Outputs | 10 |
| Polarity | Non-Inverting |
| Power Dissipation | 200 mW |
| Propagation Delay | 350 ns |
| Quiescent Current | 100 µA |
| Supply Type | Dual |
| Termination | Through Hole |
