| Pin | Symbol | Description |
|---|---|---|
| 1 | I6 | data input |
| 2 | I7 | data input |
| 3 | NC | no connection |
| 4 | I8 | data input |
| 5 | ΣE | even parity output |
| 6 | ΣO | odd parity output |
| 7 | GND | ground |
| 8 | I0 | data input |
| 9 | I1 | data input |
| 10 | I2 | data input |
| 11 | I3 | data input |
| 12 | I4 | data input |
| 13 | I5 | data input |
| 14 | Vcc | supply voltage |
