75454 Pinout
75454 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | 1A | Input Pin 1A |
| 2 | 1B | Input Pin 1B |
| 3 | 1Y | Output Pin 1Y |
| 4 | GND | Ground Pin |
| 5 | 2Y | Output Pin 2Y |
| 6 | 2A | Input Pin 2A |
| 7 | 2B | Input Pin 2B |
| 8 | VCC | Collector Supply Voltage |
75454 Key Features
- Characterized for Use to 300 mA
- High-voltage outputs up to 30 V
- No Output Latch-Up at 20 V (After Conducting 300 mA)
- High-Speed Switching
- Open-Collector Outputs
- Circuit Flexibility for Varied Applications
- TTL-Compatible Diode-Clamped Inputs
- Standard Supply Voltages
Application
- High-Speed Logic Buffers
- Power Drivers
- Lamp Drivers
- LED Drivers
- Line Drivers
- Memory Drivers
DS75454 Datasheet
