Back to Back Vertical RJ45 8 Pin Panel Mountable
This back-to-back RJ45 coupler provides two vertically oriented RJ45 8P8C female connectors mounted on opposite sides of a PCB. Engineered for panel mounting, it features dual Ø3.5 mm holes for secure attachment. The straight-through wiring ensures each pin maps directly from one socket to the other, making it ideal for extending Ethernet or data connections through control panels and enclosures. The compact module measures just 46 mm × 16 mm × 19 mm, offering a neat and reliable interface.
Features
- Two vertical RJ45 (8P8C) female connectors, mounted back-to-back on PCB.
- Straight-through wiring: each pin 1 → 1, …, 8 → 8 between sockets.
- Two Ø3.5 mm mounting holes enable panel or chassis attachment.
- Compact PCB dimensions of 46 × 16 × 19 mm for tight spaces.
Specifications
| Parameter | Value |
|---|---|
| Connectors | 2 × RJ45 female (8P8C), vertical |
| Wiring | Straight-through |
| Mounting Holes | 2 × Ø3 mm |
| PCB Dimensions | 46 mm × 16 mm × 19 mm |
| Panel Compatibility | Panel-mountable chassis installation |
Applications
- Panel-mounted Ethernet/data feed-throughs in equipment cabinets.
- Network extension in industrial and telecom panels.
- Clean passthrough solutions in DIY enclosures and jigs.
- Test and measurement setups requiring removable RJ45 access.
Package Contents
- 1x Back to Back Vertical RJ45 8 Pin Panel Mountable.
