BC637 – High Current NPN Transistor (60V, 1A)

0.75 EGP

Buy Now
Availability: In Stock
SKU:34963000598510

BC637 is a semiconductor device used to amplify or switch electronic signals and electrical power. It is composed of semiconductor material usually with at least three terminals for connection to an external circuit. A voltage or current applied to one pair of the transistor’s terminals controls the current through another pair of terminals. Because the controlled (output) power can be higher than the controlling (input) power, a transistor can amplify a signal. Today, some transistors are packaged individually, but many more are found embedded in integrated circuits.

Features:-

  • Advanced process technology
  • Low error voltage
  • Fast switching speed
  • Full-voltage operation
  • High power and current handling capability

Detailed Specifications:-

Transistor Polarity NPN
Collector-Emitter Breakdown Voltage (BVCEO) 60V
Collector-Emitter Voltage (VCEO) 60V
Emitter-Base Voltage (VEBO) 5V
Continuous Collector Current (IC) 1A
Base Current (IB) 100mA
Transition Frequency (fT) 100MHz
DC Current Gain (hFE) 40-160
Operating Temperature Range -65 – 150°C
Collector Power Dissipation (PC) 1W

Related Documents:-

 BC637 Transistor Datasheet
