Bridge Rectifier 3 Phase SKBPC5016 50A 5 Terminals
The Bridge Rectifier 3 Phase SKBPC5016 50A 5 Terminals is a high-performance component engineered for converting three-phase alternating current (AC) to direct current (DC) in a wide range of industrial and commercial applications. With a maximum repetitive peak reverse voltage of 1600V and an average rectified output current of 50A, this rectifier is well-suited for demanding power supply systems that require robust and efficient power conversion.
Features:
- Low cost
- High forward surge current capability
- High isolation voltage from case to leads
Specifications:
| SYMBOLS | SKBPC5016 | UNITS | |
| Maximum Repetitive Peak Reverse Voltage | VRRM | 1600 | Volts |
| Maximum RMS Voltage | VRMS | 1120 | Volts |
| Maximum DC Blocking Voltage | VDC | 1600 | Volts |
| Maximum Average Forward
Rectified Output Current, at TC=50℃(Note1,2) |
I(AV) | 50 | Amps |
| Peak Forward Surge Current 8.3ms single half
sine-wave superimposed on rated load (JEDEC Method) |
IFSM |
500 |
Amps |
| Rating for Fusing(t<8.3ms) | I2T | 1040 | A2S |
| Maximum Instantaneous Forward Voltage at 1A | VF | 1.2 | Volts |
| Isolation Voltage from case to lugs | VISO | 2500 | VAC |
| Typical Thermal Resistance per element | ReJA | 0.9 | ℃/W |
| Operating Temperature Range | TJ | -40 to +150 | ℃ |
| Storage Temperature Range | TSTG | -40 to +150 | ℃ |
Applications:
- Industrial power supplies.
- Motor control systems.
- Battery charging systems.
- Welding machines.
- Uninterruptible power supplies (UPS).
- Renewable energy systems.
