Features
- Low reverse leakage
- High forward surge capability
- A Surge overload rating:200 Amperes peak
- Lead and body according with RoHS standard
Mechanical Data
- Case: Molded Plastic
- Polarity: Symbols molded or marked on body
- Mounting Position: Any
Mechanical Dimensions:
Specifications
| Parameter | Symbol | kbl1010 | unit |
| Maximum repetitive peak reverse voltage | VRRM | 1000 | V |
| Maximum RMS bridge input voltage | VRMS | 700 | V |
| Maximum DC blocking voltage | VDC | 1000 | V |
| Maximum average forward rectified output current at TC=55°C | IF(AV) | 10 | A |
| Peak forward surge current 8.3 ms single half sine-wave | IFSM | 300 | A |
| Operating junction and storage temperature range | TJ, TSTG | -55 to + 150 | °C |
