Description :
The GX16-10 Pin Chassis Connector is a high-quality aviation-style connector designed for secure and stable electrical connections in industrial, automation, and DIY applications. With a robust metal housing, it ensures durability and long-lasting performance
Key Features:
- 10-Pin Configuration – Supports multi-signal connections in a compact design.
- Durable Metal Construction – Corrosion-resistant and wear-proof for long-term use.
- Secure Locking Mechanism – Prevents accidental disconnections.
- Screw-Terminal Contacts – Easy to wire and assemble without soldering.
- Versatile Applications – Ideal for industrial equipment, CNC machines, robotics, and audio devices.
Technical Specifications:
- Connector Type: Aviation Chassis Connector (Male & Female)
- Model: GX16-10
- Number of Pins: 10
- Material: Nickel-plated metal shell for enhanced durability
- Mounting Type: Panel mount (female) & cable mount (male)
- Contact Resistance: ≤ 5mΩ
- Insulation Resistance: ≥ 1000MΩ at 500V DC
- Rated Voltage: 250V
- Rated Current: 5A
- Operating Temperature: -40°C to +85°C
- Connection Type: Screw terminals
Applications:
- Industrial Equipment & Automation – CNC machines, control panels, PLCs.
- Aviation & Marine Electronics – Secure signal transmission in harsh environments.
- Robotics & DIY Projects – Custom electronic and embedded system applications.
- Audio & Communication Systems – Professional sound equipment and custom wiring setups.
- Power & Signal Connections – Reliable multi-pin connectivity in power systems.
