COMPTYCO AUA-MC70 Optical Power Meter -70~+10dBm
The COMPTYCO AUA-MC70 Optical Power Meter -70~+10dBm is a multifunctional, compact device engineered for comprehensive fiber optic testing and maintenance, ideal for professionals in telecommunications, data centers, and smart electronics applications. It integrates four key functions: an Optical Power Meter, Visual Fault Locator, LED light source, and RJ45 network cable tester. With a measurement range of -70 dBm to +10 dBm and support for multiple wavelengths, it provides accurate power measurements for various fiber optic systems. The device features a user-friendly backlit LCD display and an intuitive keypad, ensuring ease of operation in diverse environments.
Its rugged, lightweight design and rechargeable lithium battery, offering up to 12 hours of continuous operation, make it highly portable for field use. This tool is particularly valuable for technical writers documenting fiber optic network installations, troubleshooting, and maintenance processes in electronics and smart device projects.
Features:
- Multifunctional Design: Integrates an Optical Power Meter (OPM), Visual Fault Locator (VFL), LED light source, and RJ45 network cable tester into a single compact device.
- Wide Measurement Range: Accurately measures optical power from -70 dBm to +10 dBm, accommodating various fiber optic applications.
- User-Friendly Interface: Features a backlit LCD display for clear readings and an intuitive keypad for easy operation.
- Durable and Portable: Designed for field use with a rugged exterior and lightweight build, facilitating convenient transport and handling.
Specifications:
| Attribute | Value |
|---|---|
| Measurement Range | -70 dBm to +10 dBm |
| Wavelength Range | 850 nm, 980 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1577 nm, 1625 nm, 1650 nm |
| Display Type | Backlit LCD Display |
| Power Source | Rechargeable Lithium Battery |
| Battery Life | Typically 10-12 hours of continuous operation |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Dimensions | 111x 69x 30 mm |
| Weight | Approx. 250 g |
| Additional Functions | Visual Fault Locator (VFL), LED light source, RJ45 network cable tester |
| Connector Type | FC, SC, LC, ST (via adapters) |
| Resolution | 0.01 dBm |
| Accuracy | ±0.2 dB (for -40 dBm to +10 dBm range) |
This table includes more specific technical information and should give you a complete view of the COMPTYCO AUA-MC70 Optical Power Meter. Let me know if you need anything else!
Applications:
- Fiber Optic Installation: Essential for verifying signal strength and quality during the setup of fiber optic networks.
- Maintenance and Troubleshooting: Helps in diagnosing issues within fiber networks by detecting faults and measuring power levels.
- Network Certification: Ensures that fiber installations meet required performance standards.
- Educational Purposes: Ideal for training environments where understanding fiber optic technology is crucial.
Package Included:
- COMPTYCO AUA-MC70 Optical Power Meter
- Rope for COMPTYCO AUA-MC70 for easy portability and secure handling during use
- User Manual for guidance on operation and maintenance of the device
