Description:
Specifications:
| Type | Description |
| Category | RF and Wireless RF Transceiver Modules and Modems |
| Mfr | Infineon Technologies |
| Series | EZ-BLE™ PSoC® |
| RF Family/Standard | Bluetooth |
| Protocol | Bluetooth v4.1 |
| Module size | 11.0 mm × 11.0 mm × 1.80 mm |
| Frequency | 2.4GHz |
| Data Rate | 1Mbps |
| Power – Output | 3dBm |
| Sensitivity | -87dBm |
| Serial Interfaces | I2C, SPI, UART |
| Antenna Type | Integrated, Trace |
| Memory Size | 128kB Flash, 16kB SRAM |
| Voltage – Supply | 1.7V ~ 5.5V |
| Current – Receiving | 16.4mA ~ 21.5mA |
| Current – Transmitting | 12.5mA ~ 20mA |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 32-SMD Module |
| Base Product Number | CYBLE-014008 |
