Delta AFB0612VHC DC Fan 12V 0.36A 60x60x25mm (USED LIKE NEW)
AFB0612VHC Compact 60×60×25 mm 12VDC brushless fan commonly used for cooling electronic enclosures and power modules.
250.00 EGP
Buy NowDelta AFB0612VHC DC Fan 12V 0.36A 60x60x25mm (USED LIKE NEW)
The Delta AFB0612VHC is a dependable 12 V DC brushless axial fan designed to provide steady airflow in medium-density electronic assemblies. Its 60 mm square frame and 25 mm thickness make it a good fit for small chassis, power supplies, telecom gear and embedded controllers where reliable forced ventilation is required.
This unit is USED – Like New (lightly used or tested, in excellent working condition). Delta’s AFB series is known for robust build quality, long life and stable operation under continuous duty — suitable for industrial and commercial thermal management applications. Specification details are taken from the official Delta product specification.
Features:
- Brushless DC motor for long life and low maintenance.
- Compact 60×60×25 mm form factor for tight spaces.
- Stable airflow suitable for continuous operation.
- Low vibration and reliable mounting options.
- Ideal for replacement or retrofit in electronics equipment.
Specifications:
| ITEM | DESCRIPTION |
|---|---|
| RATED VOLTAGE: | 12 VDC |
| OPERATION VOLTAGE: | 7.0 – 13.8 VDC |
| START VOLTAGE (ENVIRONMENT TEMPERATURE 25°C): | < 5.0 VDC |
| INPUT CURRENT: | 0.24 (MAX. 0.36) A |
| INPUT POWER: | 2.88 (MAX. 4.32) W |
| SPEED: | 5400 R.P.M. (REF.) |
| MAX. AIR FLOW: | 0.785 (MIN. 0.707 ) M³/MIN. |
| (AT ZERO STATIC PRESSURE): | 27.72 (MIN. 24.97 ) CFM |
| MAX. AIR PRESSURE: | 6.41 (MIN. 5.19 ) mmHg |
| (AT ZERO AIRFLOW): | 0.252 (MIN. 0.204 ) inch H₂O |
| ACOUSTICAL NOISE (AVG): | 38.0 (MAX. 42.0) dB-A |
| INSULATION TYPE: | UL: CLASS A |
| INSULATION STRENGTH: | 10 MEG OHM MIN. AT 500 VDC (BETWEEN FRAME AND (+) TERMINAL) |
| DIELECTRIC STRENGTH: | 5 mA MAX. AT 500 VAC 60 Hz ONE MINUTE, (BETWEEN FRAME AND (+) TERMINAL) |
| EXTERNAL COVER: | OPEN TYPE |
| LIFE EXPECTANCE: | 70,000 HOURS CONTINUOUS OPERATION AT 40 °C WITH 15 ~ 65 %RH. |
| ROTATION: | CLOCKWISE VIEW FROM NAME PLATE SIDE |
| OVER CURRENT SHUT DOWN: | THE CURRENT WILL SHUT DOWN WHEN LOCKING ROTOR. |
| LEAD WIRE: | UL 1007 –F– AWG #28 BLACK WIRE NEGATIVE(–) RED WIRE POSITIVE(+) BLUE WIRE LOCK SIGNAL(-ROO) |
Applications:
- Cooling electronic enclosures and control boxes.
- Power supply and DC-DC converter ventilation.
- Networking / telecom equipment.
- Embedded systems and small industrial controllers.
- Replacement fan for repair and maintenance.
Packages:
- 1x Delta AFB0612VHC DC Fan 12V 0.36A 60x60x25mm (USED LIKE NEW).
| Weight | 34 g |
|---|---|
| Dimensions | 60 × 60 × 25 mm |
