DIP Switch 4 Way – Long Leg
The DIP Switch 4 Way – Long Leg is a versatile switch designed for electronic projects that require reliable and secure connections. Unlike traditional DIP switches, this switch features long legs, making it easy to insert into breadboards and ensuring a firm connection, ideal for both professional and hobbyist use. The switch is configured with 4 distinct positions, offering flexibility for different settings.
Features:
- 4-way switch with long legs for easy breadboard integration.
- Rated for 100mA current and 50V voltage for versatile use in electronics.
- SPST (Single Pole Single Throw) design for simple on/off functionality.
- Ideal for use in breadboards and DIP IC packages.
Specifications:
| COLOUR | Black |
| PACKAGE | DIP |
| NUMBER OF PINS/CONDUCTORS | 8 |
| RATED CURRENT | 100mA |
| RATED VOLTAGE | 50V |
| OPERATING TEMPERATURE | -20°C to 85°C |
| TYPE | SPST |
| POSITIONS | 4 |
| CONTACT RESISTANCE | 50mΩ max |
| INSULATION RESISTANCE | 1000MΩ at 500V DC |
| SWITCHING LIFE | 2,000 cycles |
| LEAD PITCH | 2.54mm |
| Number of Positions | 4 |
Applications:
- Ideal for electronics prototyping and testing.
- Commonly used in embedded systems and circuit designs.
- Suitable for DIY projects and breadboard-based experiments.
- Can be used in computer hardware and control systems.
Drawing:
Package Include:
1x DIP Switch 4 Way – Long Leg
