ELECROW CrowPanel 2.8″ HMI ESP32 Display 320×240 SPI TFT LCD Touch Screen With Acrylic Case
Elecrow CrowPanel 2.8″-HMI ESP32 Display is a compact and versatile human-machine interface (HMI) module designed for Internet of Things (IoT) and embedded applications.
1,750.00 EGP
Buy NowELECROW CrowPanel 2.8″ HMI ESP32 Display 320×240 SPI TFT LCD Touch Screen With Acrylic Case
The ELECROW CrowPanel 2.8″ HMI ESP32 Display is a compact and efficient human-machine interface (HMI) solution, featuring a 2.8-inch TFT LCD touchscreen with a 320×240 pixel resolution. This module combines the power of the ESP32 chip, which offers both Wi-Fi and Bluetooth connectivity, making it an ideal choice for embedded systems, IoT devices, and portable electronics that require user interaction.
The CrowPanel 2.8″ provides an intuitive, responsive touch interface, enabling developers to create highly interactive and sophisticated applications. With the included SPI interface, the module ensures compatibility with a wide range of microcontrollers and development platforms, including Arduino and ESP32, while offering flexibility and ease of integration. The module also comes with an acrylic case, providing protection and durability for both prototypes and finished products.
Features:
- 2.8-inch TFT LCD touchscreen with 320×240 pixel resolution for clear visuals.
- Built-in ESP32 chip supporting Wi-Fi and Bluetooth connectivity.
- SPI interface for easy integration with microcontrollers.
- Capacitive touchscreen for smooth and precise touch input.
- Compact design with included acrylic case for durability.
- Compatible with Arduino and ESP32 development platforms.
- Ideal for IoT, smart home, and embedded system projects.
Specifications:
| Category | Specification |
|---|---|
| Model | 2.8 inches CrowPanel ESP32 display |
| Main Processor | ESP32-WROOM-32-N4 |
| Resolution | 320 × 240 |
| Touch Type | Resistive Touch Screen |
| Display Type | TN Panel |
| Screen | TFT-LCD Screen |
| Display Driver | ILI9341V |
| External Power Supply | DC 5V-2A |
| Interface | 1× TF Card Slot, 1× I2C, 1× GPIO, 1× Speaker, 1× UART1, 1× UART0 |
| Button | BOOT Button and Reset Button |
| Dimension | 88.5× 56.5mm (L× W) |
| Working Temperature | -20℃ to 70℃ |
| Storage Temperature | -30℃ to 80℃ |
Configuration:
Applications:
- Human-machine interfaces for IoT devices.
- Smart home and automation control systems.
- Sensor data displays for embedded systems.
- Portable devices requiring a touchscreen interface.
- Robotics and mechatronics projects.
- Control panels for industrial systems.
Package Include:
- 1x CrowPanel ESP32 Display-2.8 Inch HMI Display.
- 1x USB-A to Type-C Cable.
- 1x Crowtail/Grove to 4pin DuPont cable.
- 1x Resistive touch pen.
Documents:
- Wiki
- User Manual
- Schematic Diagram
- 3D File
- Specification of LCD
- ESP32-WROOM-32-N4 Datasheet
- Outline Dimensions
- LVGL Reference
- openHASP Github
- For Tactility
- CE Certificate
- Distributor Certificate
