Electrolytic Capacitor 25V 1000uF
An Electrolytic Capacitor 25V 1000µF is a polarized capacitor designed for applications requiring high capacitance in a compact size. With a voltage rating of 25 volts and a capacitance of 1000 microfarads, it is commonly used for filtering, smoothing, and energy storage in DC power supply circuits. This capacitor helps reduce voltage ripple, stabilize voltage levels, and filter out noise, making it ideal for use in audio equipment, power adapters, automotive electronics, and general-purpose electronic devices. Its aluminum construction and electrolyte dielectric allow for high energy density, while its through-hole design ensures easy integration into various circuit boards.
Features:
- High capacitance for bulk energy storage.
- Compact size relative to its capacity.
- Suitable for power supply filtering, decoupling, and energy storage.
- Economical and widely available.
- Common in audio, power supplies, and general-purpose circuits.
Specifications:
- Technology: Electrolytic
- Capacitance: 1000µF
- Voltage: 25VDC
- Ripple Current: 220mA
- Leakage Current: <=0.03 CV or 3 μA @ 1 min
- Tolerance: ±20%
- Dissipation Factor: 20%
- Lifetime: 2000h
- Polarized: Polar
- Mounting Type: Through Hole
- Terminal Type: Radial
- Number Terminals: 2
- Shape: Cylindrical
- Height: 16.8mm
- Diameter: 10mm
- Lead Spacing: 5mm
- Minimum Operating Temperature: -25°C
- Maximum Operating Temperature: +105°C
Applications:
- Power Supply Filtering and Smoothing.
- Decoupling and Bypass.
- Audio Systems.
- Motor Start/Run Capacitors.
- Pulse Power Applications.
- Energy Storage.
- Automotive Electronics.
- Inrush Current Limiting.
Package Contents:
1 X Electrolytic Capacitor 25V 1000uF
