FANHAR Power Relay FH19-1A2S-DC24V 5A 4 Pin

FANHAR Power Relay FH19-1A2S-DC24V 5A 4 Pin

The FANHAR Power Relay FH19-1A2S-DC24V 5A 4 Pin is a compact electromagnetic switching device engineered for reliable performance in space-constrained electronic applications. Featuring a bifurcated welded double contact structure, it ensures stable and low-resistance connections, minimizing contact bounce and enhancing signal integrity during operation. With a slim profile of just 5mm thickness, this relay supports high-density installation on printed circuit boards, making it suitable for modern electronics where miniaturization is key.

Features:

• Bifurcated welded double contact structure for stable connections.
• Slim 5mm thickness suitable for high-density PCB installation.
• High-sensitive coil with 120mW power consumption for energy efficiency.
• Plastic-sealed construction for environmental protection.

Specifications:

• Product type: FH19
• 5A switching capability
• Coil voltage: 24V
• The thickness of the product is 5mm, suitable for high density installation
• High sensitive type, coil power is 120mW
• UL insulation system: Class F
• Environment-friendly product(RoHS compliant)
• Outline Dimensions: (20.2×5.2×12.5)mm
• Main application: Industrial Control
• Functions equal to: HF49FD(Hongfa), G6DS(Omron), PA/APAN3(Panasonic), PCN(TE)

Applications:

• Industrial control systems for switching operations.
• Automation equipment requiring precise relay control.
• Power management in electronic devices.
• Solenoid and motor drivers in machinery.
• Lighting control circuits for efficiency.
• Signal switching in smart electronics.

Package Include:

1x FANHAR Power Relay FH-19-1A2S-DC24V 5A 4 Pin

Datasheet:

FH19
