FANHAR Power Relay W15-2CST-DC12V 8A 8 Pin
High‑quality FANHAR W15‑2CST‑DC12V 8A 8‑pin power relay featuring a 12 V DC coil and capable of switching up to 8 A
85.00 EGP
Buy NowFANHAR Power Relay W15-2CST-DC12V 8A 8 Pin
The FANHAR W15‑2CST‑DC12V 8A 8 Pin Power Relay is designed for reliable and rigorous switching applications in circuits requiring a compact 8‑pin footprint with robust performance. This model is specified with a 12 V DC coil voltage, which makes it suitable for control systems and automation requiring a low‑voltage drive. With its rated switching capability of up to 8 A, it handles moderate loads efficiently while maintaining solid mechanical and electrical endurance.
Features:
- 8A resistive switching capacity on dual poles.
- 12VDC coil voltage for energy-efficient operation.
- 8-pin DPDT arrangement for versatile circuit integration.
- High dielectric strength: 2.5kV (contacts), 5kV (coil to contacts).
- Quick response: operate ≤15ms, release ≤5ms.
- PCB-mount form factor (approx. 28.8 × 12.5 × 15.7 mm).
Specifications:
| Parameter | Value |
|---|---|
| Manufacturer | FANHAR |
| Model Number | W15-2CST-DC12V |
| Contact Arrangement | DPDT (2C) |
| Rated Coil Voltage | 12VDC |
| Rated Load | 8A 250VAC/30VDC |
| Max Switching Voltage | 277VAC/30VDC |
| Max Switching Current | 12A |
| Contact Material | AgNi/AgSnO2 |
| Operate Time | ≤15ms |
| Release Time | ≤5ms |
| Insulation Resistance | ≥1000MΩ @ 500VDC |
| Dielectric Strength (Contacts) | 2.5kV |
| Dielectric Strength (Coil/Contacts) | 5kV |
| Shock Resistance | 10g functional, 100g destructive |
| Vibration Resistance | 10–55Hz, 1.5mm DA |
| Ambient Temperature | –40°C to +85°C/105°C |
| Mounting | PCB |
| Dimensions | 28.8×12.5×15.7mm |
Applications:
- Control switching in smart‑home modules and IoT devices.
- Industrial automation panels and control systems.
- Interface of low‑voltage electronics to higher‑power AC or DC loads.
- Switching of motors, relays or solenoids within specified load limits.
- General purpose electronics projects requiring PCB‑mountable relays.
Package Include:
1x FANHAR Power Relay W15-2CST-DC12V 8A 8 Pin.
Datasheet:
W15-2
