G40T65FUK IGBT Transistor 650V 80A TO-247

G40T65FUK IGBT: 650V 80A TO-247. Features Trench Field Stop technology, low VCE(sat), and fast switching. Ideal for welding, UPS, and air conditioning systems.

80.00 EGP

Buy Now
Availability: In Stock
SKU:3496300134601
Categories:
Tags:, , , ,
G40T65FUK IGBT Transistor 650V 80A TO-247

The BLG40T65FUK is a high-performance IGBT manufactured using advanced Trench Field Stop (T-FS) technology. This technology provides the device with a low collector-emitter saturation voltage (), optimized switching performance, and a low gate charge (). It is designed as a highly efficient and reliable component for power conversion and high-frequency switching applications.

✅Features
  • Technology: Advanced Trench Field Stop (T-FS) technology.
  • Switching Speed: Fast switching capability for reduced power loss.
  • Saturation Voltage: Low for improved efficiency.
  • Thermal Stability: Features a positive temperature coefficient.
  • Integrated Diode: Includes a fast recovery anti-parallel diode.
  • Compliance: RoHS compliant product.
📜📚Specifications
Absolute Maximum Ratings (TC = 25°C)
Collector-Emitter Voltage (VCES) 650 V
Gate-Emitter Voltage (VGES) ±30 V
Continuous Collector Current (TC = 25°C) 80 A
Continuous Collector Current (TC = 100°C) 40 A
Pulsed Collector Current (ICM) 160 A
Diode Continuous Forward Current (TC = 25°C) 40 A
Short Circuit Withstand Time (tsc) 3.0 µs
Power Dissipation (PD) 298 W
Operating Junction Temperature (TJ) -55 to 175 °C
Static Characteristics
Collector-Emitter Saturation Voltage (VCE(sat)) 1.55 (Typ) / 1.95 (Max) V
Gate Threshold Voltage (VGE(th)) 4.8 to 6.2 (5.5 Typ) V
Collector-Emitter Leakage Current (ICES) 4.0 (Max) µA
Gate-Emitter Leakage Current (IGES) 200 (Max) nA
Dynamic & Thermal Characteristics
Input Capacitance (Ciss) 2225 pF
Total Gate Charge (Qg) 110 nC
Thermal Resistance, Junction-to-Case (RθJC) 0.5 °C/W
Thermal Resistance, Junction-to-Ambient (RθJA) 40 °C/W

💻Applications
  • Welding Converters
  • Uninterruptible Power Supplies (UPS)
  • Boost Choppers
  • Air Conditioning systems
  • High switching frequency applications
🎁Package Content
  • 1 x G40T65FUK IGBT Transistor 650V 80A TO-247
📖DataSheet
