IRF9530 P-Channel Power MOSFET TO-220 (14A-100V-0.2Ω)

25.00 EGP

Buy Now
Availability: In Stock
SKU:1746589086910

IRF9530 is new generation of high voltage MOSFET family that is utilizing an advanced charge balance mechanism for outstanding low on-resistance and lower gate charge performance. This advanced technology has been tailored to minimize conduction loss, provide superior switching performance, and withstand extreme dv/dt rate and higher avalanche energy. It is very suitable for various AC/DC power conversion in switching mode operation for system miniaturization and higher efficiency.

Features:-
  • Dynamic dV/dt rating
  • 100% avalanche rated
  • Fast switching
  • Ease of paralleling
  • New high voltage benchmark
  • P-Channel
Detailed Specifications:-
Number of Channels 1 Channel
Transistor Polarity P-Channel
Drain-Source Breakdown Voltage (Vds) -100V
Continuous Drain Current (Id) -14A
Drain-Source Resistance (Rds On) 0.20Ohms
Gate-Source Voltage (Vgs) 20V
Gate Charge (Qg) 58 nC
Operating Temperature Range -55 – 175°C
Power Dissipation (Pd) 79W
Related Documents
 IRF9530 MOSFET Datasheet
