K817 N-Channel MOSFET Transistor 60V 26A TO-220F
High-power K817 N-channel MOSFET, 60V 26A, TO-220F package, low on-resistance, ideal for motor drive and power switching.
15.00 EGP
Buy NowK817 N-Channel MOSFET Transistor 60V 26A TO-220F
The K817 is a high-power N-channel MOSFET designed for efficient switching in electronic and power-control circuits. It is built to handle up to 60V drain-source voltage and 26A continuous drain current, making it suitable for demanding load-control tasks.
With a low on-resistance of up to 55mΩ at VGS = 10V, the device helps reduce power loss and heat generation during operation. The datasheet also shows a high single-pulse drain current rating of 104A, which supports short burst loads and switching events.
The K817 is intended for motor drive, DC-DC converter, power switch, and solenoid drive applications. It also includes 100% avalanche testing and stable device-to-device performance, which helps improve reliability in real-world circuits.
Features:
- N-Channel MOSFET transistor.
- 60V drain-source voltage rating.
- 26A continuous drain current.
- 104A single pulse drain current capability.
- Low RDS(on) for efficient switching.
- 100% avalanche tested.
- Suitable for robust and reliable operation.
Specifications:
| Parameter | Value |
|---|---|
| Product Name: | K817 N-Channel MOSFET Transistor |
| Drain-Source Voltage (VDSS): | 60V |
| Gate-Source Voltage (VGS): | ±20V |
| Continuous Drain Current (ID): | 26A |
| Single Pulse Drain Current (IDM): | 104A |
| Total Dissipation (PD): | 35W |
| Maximum Junction Temperature (TJ): | -55°C to 150°C |
| Storage Temperature (Tstg): | -55°C to 150°C |
| Thermal Resistance, Junction to Case (Rth j-c): | 3.57°C/W |
| Drain-Source Breakdown Voltage: | 60V |
| Gate Threshold Voltage: | 1.0V to 2.5V |
| Drain-Source On-Resistance: | 55mΩ max |
| Gate-Body Leakage Current: | ±0.1µA max |
| Zero Gate Voltage Drain Current: | 10µA max |
| Forward On-Voltage: | 1.7V max |
Applications:
- Motor drive.
- DC-DC converter.
- Power switch.
- Solenoid drive.
Package Contents:
- 1x K817 N-Channel MOSFET Transistor 60V 26A TO-220F
