Features:
- Internally adjustable input offset voltage.
- Low power consumption.
- Wide common-mode (up to VCC+) and differential voltage range.
- Low input bias and offset current.
- Output short-circuit protection.
- High input impedance JFET input stage.
- Internal frequency compensation.
- Latch up free operation.
- High slew rate.
- Low input noise voltage.
- Low input noise current.
- Wide gain bandwidth.
- Low supply current.
- Low total harmonic distortion.
- High speed JFET input single operational amplifiers incorporating well matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit.
Pin Configuration:
Specifications:
| Product Attribute | Attribute Value |
| Datasheet | LF356N |
| Product Category | Operational Amplifiers-Op Amps |
| Number of Channels | 1 Channel |
| GBP – Gain Bandwidth Product | 5 MHz |
| SR – Slew Rate | 12 V/us |
| Vos – Input Offset Voltage | 10 mV |
| Ib – Input Bias Current | 200 pA |
| Supply Voltage – Max | 36 V, +/- 18 V |
| Supply Voltage – Min | 10 V, +/- 5 V |
| Operating Supply Current | 10 mA |
| CMRR-Common Mode Rejection Ratio | 80 dB |
| en-Input Voltage Noise Density | 15 nV/sqrt Hz |
| Package/Case | DIP-8 |
| Mounting Style | Through Hole |
| Shutdown | No Shutdown |
| Operating Temperature | 0 °C to + 70 °C |
| Series | LF356 |
| In – Input Noise Current Density | 0.01 pA/sqrt Hz |
| Maximum Dual Supply Voltage | +/- 18 V |
| Minimum Dual Supply Voltage | +/- 5 V |
| Operating Supply Voltage | 10 V to 36 V, +/- 5 V to +/- 18 V |
| Pd – Power Dissipation | 670 mW |
| PSRR-Power Supply Rejection Ratio | 80 dB |
| Factory Pack Quantity | 40 |
| Supply Type | Dual |
| Voltage Gain dB | 106.02 dB |
Applications:
- Square Wave oscillator.
- High Q Notch Filter.
- Sample and Hold Circuit.
- In circuits that need high input impedance and high-speed integrators.
- Quick digital to analog converters.
- Sample and hold circuits, etc.
