Features
- Internally Trimmed Offset Voltage: 1 mV (Max)
- Input Offset Voltage Drift: 7 uV/°C (Typ)
- Low Input Bias Current: 50 pA
- Low Input Noise Current: 0.01 pA / √Hz
- Wide Gain Bandwidth: 3 MHz (Min)
- High Slew Rate: 10V/us (Min)
- Low Supply Current: 1.8 mA/Amplifier
- High Input Impedance: 10 12Ω
- Low Total Harmonic Distortion: ≤0.02%
- Low 1/f Noise Comer: 50 Hz
- Fast Setting Time to 0.01%: 2 us
Product Attributes
| Type | Description |
| Category | Linear
Amplifiers Instrumentation, Op Amps, Buffer Amps |
| Amplifier Type | J-FET |
| Number of Circuits | 2 |
| Slew Rate | 15V/µs |
| Gain Bandwidth Product | 4 MHz |
| Current – Input Bias | 50 pA |
| Voltage – Input Offset | 1 mV |
| Current – Supply | 3.6mA (x2 Channels) |
| Voltage – Supply Span (Min) | 10 V |
| Voltage – Supply Span (Max) | 36 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP |
Applications
- High Speed Integrators
- Fast D/A Converters
- Sample and Hold Circuits
