LS 26500 Saft C Lithium Battery 3.6V 8500mAh
The LS 26500 is a high-performance 3.6V, 8500mAh,C-size lithium battery designed for applications that require long operational life, reliability, and resistance to harsh environmental conditions. It is commonly used in utility metering, medical devices, security systems, industrial sensors, and tracking systems. This battery uses lithium-thionyl chloride (Li-SOCl₂) chemistry, providing high energy density, low self-discharge, and stable performance over time. It is built for low-drain and moderate-drain applications, ensuring a long lifespan with minimal maintenance.
Features:
- Provides long-lasting power for extended operation.
- Low Self-Discharge rate where approximately 1% per year, allowing for a shelf life of up to 10+ years.
- Wide Operating Temperature Range where Performs well in extreme temperatures from -60°C to +85°C.
- Stable Voltage Output where ensures consistent performance throughout its discharge cycle.
- Designed to prevent leaks, ensuring safe and reliable operation.
- Provides a better energy-to-weight ratio than many other battery chemistries.
- High voltage response.
- Easy integration into compact systems.
- Superior resistance to atmosphere corrosion.
- Stainless steel container and end caps.
- Low magnetic signature.
- Hermetic glass-to-metal sealing.
- Non-flammable electrolyte.
- Underwriters Laboratories Component Recognition.
Specifications:
- Battery Chemistry: Lithium Thionyl Chloride (Li-SOCl)
- Nominal Voltage: 3.6V
- Battery Capacity: 8500 mAh
- Maximum Continuous Current: 100mA
- Maximum Pulse Current: 400mA
- Battery Size: C
- Terminal Type: Finished version with flat positive end cap
- Battery Shelf Life: 10 Years
- Self-Discharge Rate: ~1% per year
- Operating Temperature Range: – 60°C to +85°C
- Dimensions:
- Diameter: 25 mm
- Height: 50.4 mm
- Weight(Approx.): 50g
Applications:
- Utility Meters (Gas, Water, Electricity).
- AMR (Automatic Meter Reading) Systems.
- Industrial Sensors & Data Loggers.
- IoT (Internet of Things) & Remote Monitoring Systems.
- GPS Tracking Devices.
- Medical Equipment (Infusion Pumps, Portable Monitors, etc.).
- Burglar Alarms & Security Systems.
- Smoke Detectors & Fire Alarm Systems.
- Emergency Backup Power.
- Military Communication Equipment.
- Emergency Beacons (EPIRBs, PLBs, ELTs).
- Space and Satellite Systems.
