MC14538BCP Dual Precision Retriggerable/Resettable Monostable Multivibrator PDIP-16

MC14538BCP Dual Precision Retriggerable/Resettable Monostable Multivibrator PDIP-16

The MC14538BCP Dual Precision Monostable Multivibrator is a CMOS timing IC featuring two independent monostable stages with retriggerable and resettable capability, housed in a standard 16-pin PDIP package. This device excels in generating single pulses of precise duration in response to input triggers, with flexibility for retriggering before timing completion and resetting asynchronously. It is widely used for timing delays, pulse stretching, frequency division, and debounce applications in digital systems. The robust CMOS design ensures low power consumption, wide operating voltage range, and good stability, making the MC14538BCP suitable for industrial, embedded, and consumer electronics requiring reliable pulse generation and timing control.

Features

• Two independent precision monostable multivibrators.
• Retriggerable and resettable timing for flexible pulse control.
• Adjustable output pulse width via external timing components.
• Wide supply voltage operation (typical CMOS range).
• Low power CMOS logic for efficient system design.
• Standard PDIP-16 package for easy through-hole mounting.

PINOUT

Specifications

Absolute Maximum Ratings

NOTE: for complete electrical specifications check the datasheet down below.

Applications

• Digital timing and delay generation.
• Pulse stretching and frequency division.
• Switch debounce circuits.
• Digital control and state logic timing.
• Embedded system timing modules.

Package Contents

• 1x MC14538BCP Dual Precision Retriggerable/Resettable Monostable Multivibrator PDIP-16.

Documents
