Features
- Universal AC input / Full range
- Withstand 300VAC surge input for 5 second
- No load power consumption<0.2W
- Miniature size and 1U low profile
- High operating temperature up to 70°C
- Protections: Short circuit / Overload / Over voltage
- Cooling by free air convection
- Compliance to IEC/EN 6035-1 (PD3) and IEC/EN61558-1, -2-16 for household appliances
- Operating altitude up to 5000 meters
- Withstand 5G vibration test
- High efficiency, long life and high reliability
- LED indicator for power on
- Over voltage category III
- 100% full load burn-in test
Specifications
| Manufacturer | MEAN WELL |
| Type of power supply | switched-mode |
| Kind of power supply | for building in, modular |
| Power | 35W |
| Output voltage | 5V DC |
| Output current | 7A |
| Number of outputs | 1 |
| Body dimensions | 99x82x30mm |
| Operating temperature | -30…70°C |
| Electrical connection | terminal block |
| Protection | anti-overload OPP, anti-overvoltage OVP, short circuit protection SCP |
| Efficiency | 82% |
| Manufacturer series | LRS-35 |
| Kind of case | 239A |
| Power consumption without load | <0.2W |
| Power supply/converter features | rated parameters obtained at full load |
| Output voltage range | 4.5…5.5V DC |
| Trade name | LRS |
