Features:
- Metal shell, anti-corrosion, anti-rust, pressure-resistant
- Waterproof sealing ring IP66, excellent waterproof performance
- Easy to install, waterproof, shockproof, and durable.
- The switch will be on when you push the button, and it will be off when you undo the button.
- Can be used for circuit control in electromagnetic starters, contactors, relays, and other electric circuits.
Specifications
Attribute | Value |
Switch Operation | Momentary (Self Return) |
Switch | NO (Normally Open) |
Mounting Type | Panel Mount |
Contact Configuration | SPST |
Push Button Style | Round |
Push Button Colour | Silver |
Panel Cut Out Diameter | 19.2mm |
Contact Material | Silver Alloy |
IP Rating | IP65 |
Voltage Rating | 48 V dc, 250V ac |
Contact Current Rating | 2 A @ 48 V dc |
Case Colour | Nickel |
Terminal Type | Screw |
