OSEPP LS-00087 18RPM DC Metal Gear Motor
The OSEPP LS-00087 18RPM DC Metal Gear Motor offers reliable low-speed, high-torque operation, perfect for robotics, automation, and DIY mechanical projects.
875.00 EGP
Buy NowOSEPP LS-00087 18RPM DC Metal Gear Motor
The OSEPP LS-00087 18RPM DC Metal Gear Motor is a robust and efficient motor designed to deliver consistent low-speed operation with high torque output. This motor is ideal for use in a variety of mechanical systems where precise, controlled movement is required. The 18RPM speed and metal gear train ensure durability, making it suitable for a wide range of applications, including robotics, DIY projects, automation systems, and more.
Features:
- High stall torque for handling heavy loads.
- Metal gear construction for increased durability and longevity.
- Straight-cut spur gearbox for efficient power transmission.
- D-shaped output shaft for secure accessory mounting.
- Wide voltage range for versatile power compatibility.
- Low no-load current for energy efficiency.
Specifications:
| Parameter | Value |
|---|---|
| Gear Ratio | 1:331 |
| Operating Voltage Range | 6 – 18 V |
| No-Load Speed | 18 rpm (±12%) |
| No-Load Current | 60 mA |
| Rated Speed | 15 rpm (±12%) |
| Rated Current | 230mA |
| Rated Torque | 3 kgf·cm |
| Stall Current (Max) | 1050 mA |
| Max Momentary Tolerance Torque | 10 kgf·cm |
| Direction | CCW |
Applications:
- Robotics projects requiring precise and low-speed motion.
- Automated systems with low-speed rotational needs.
- DIY mechanical projects and models.
- Driving systems in robotic platforms and other motion control mechanisms.
Package Include:
1x OSEPP LS-00087 18RPM DC Metal Gear Motor.
