Three night vision modes.
When extra lighting is not a necessity to you, simply switch the camera to black-and-white night vision mode via the EZVIZ App to turn off the spotlights. What’s even greater is that you can select smart night vision mode. In this mode, the C3N will automatically switch from black-and-white monitoring to color monitoring, turning on the spotlights when it detects human movement. The alert video will be recorded in full-color, so you get all the details needed.
AI-powered person detection.
As an upgrade from simple motion detection, the embedded AI algorithm intelligently detects the motion of human shapes in real-time. When people enter your customized detection area, you will be alerted immediately.
Built to last.
The smart camera’s whole metallic enclosure provides stronger protection and enhanced heat dissipation. Plus, with an IP67 rating, it can withstand rainy, sunny, stormy, and even snowy days. Together, the C3N gives you worry-free protection throughout the year.
Easy installation.
The C3N camera features a 360° swivel and base so that you can install it on your ceiling or wall securely. With a few steps, your own sophisticated security system will be operating smoothly.
| Model Parameters | ||
|---|---|---|
| Model | CS-C3N-A0-3H2WFRL | |
| Camera | ||
| Image Sensor | 1/2.7” Progressive Scan CMOS | |
| Shutter Speed | Self-adaptive shutter | |
| Lens | 2.8 mm @ F2.0, view angle: 104° (Horizontal), 125° (Diagonal) 4 mm @ F2.0, view angle: 86° (Horizontal), 102° (Diagonal) | |
| Lens Mount | M12 | |
| Day & Night | IR-cut filter with auto-switching | |
| DNR | 3D DNR | |
| WDR | Digital WDR | |
| Compression | ||
| Video Compression | H.264 / H.265 | |
| Video Bit Rate | Ultra-HD; HD; Standard. Adaptive bit rate. | |
| Image | ||
| Max. Resolution | 1920 × 1080 | |
| Frame Rate | Max: 30 fps; Self-adaptive during network transmission | |
| BLC | Supports | |
| Interface | ||
| Storage | Micro SD card slot (max. 256 GB) | |
| Wired Network | RJ45 × 1 (10 M/100 M Self-adaptive Ethernet port) | |
| Network | ||
| Smart Alarm | AI-powered person detection | |
| Wi-Fi Pairing | AP pairing | |
| Protocol | EZVIZ cloud proprietary protocol | |
| Interface Protocol | EZVIZ cloud proprietary protocol | |
| Max. Bitrate | 2 Mbps | |
| Wi-Fi | ||
| Standard | IEEE802.11 b/g/n | |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz | |
| Channel Bandwidth | Supports 20 MHz | |
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK | |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps | |
| General | ||
| Operating Conditions | Temperature: -30°C to 60°C (-22°F to 140°F), humidity: 95% or less (non-condensing) | |
| Power Supply | DC 12V / 1A | |
| Power Consumption | Max. 7W | |
| IP Grade | IP67 | |
| Night Vision Distance (Black/White Night Vision Mode) | Max. 30 meters (98.43 ft.) | |
| Audio Reception | Max. 5 meters (16.4 ft.) | |
| Dimensions | 75.5 × 75.5 × 155 mm (2.97 × 2.97 × 6.10 inch) | |
| Packaging Dimensions | 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) | |
| Weight | 422 g (0.93 lbs) | |
