RGB LED Mobile Phone Bluetooth Controller 5-24V
The RGB LED Mobile Phone Bluetooth Controller 5-24V is a smart lighting control device designed to manage RGB LED strips or modules through a Bluetooth connection using a mobile app. It allows users to customize lighting colors, brightness, and dynamic effects directly from their smartphone without the need for a remote control. The controller supports a wide voltage input range of 5V to 24V, making it compatible with various LED strip types. Through the dedicated mobile app, users can choose from millions of colors, adjust speed and brightness, and synchronize lighting with music for an enhanced visual experience. Compact and easy to install, this controller is ideal for home decoration, automotive lighting, or entertainment setups where wireless lighting control is desired.
Features
- Bluetooth wireless control via smartphone app (Android and iOS compatible).
- Wide input voltage range of 5V to 24V for compatibility with various RGB LED strips.
- Millions of color options with adjustable brightness and speed settings.
- Music and microphone modes synchronize light effects with songs or ambient sounds.
- Multiple dynamic lighting modes such as flash, fade, jump, and strobe.
- Memory function retains the last used settings when powered off.
- Easy plug-and-play installation with compact and lightweight design.
- Low power consumption and reliable performance for long-term use.
- Supports RGB LED strips with common anode (+) connection type.
- App-based timer control for automatic on/off scheduling.
Specifications
| Parameter | Specification |
| Product Type | RGB LED Bluetooth Controller |
| Control Method | Mobile App via Bluetooth |
| Input Voltage | DC 5V – 24V |
| Output Type | RGB (3 Channels) |
| Maximum Output Current | 4A per Channel (Max 12A Total) |
| Maximum Power | 144W |
| Bluetooth Version | BLE V4.2 |
| Bluetooth Control Distance | Up to 20 meters (open area) |
| Compatibility | Android & iOS Devices |
| Connection Type | Common Anode (+) |
| Lighting Modes | Static Color, Flash, Fade, Jump, Strobe, Music Sync |
| Operating Temperature | -25°C to +75°C |
| App Name | LED BLE / Happy Lighting / Magic Home |
| Material | ABS Plastic Housing |
| Memory Function | Yes |
Applications
- Home and interior lighting for mood and decorative effects.
- Car and motorcycle ambient lighting or undergrow LED setups.
- Party and event lighting with music-synchronized effects.
- Shop and display lighting to highlight products with vibrant colors.
- Architectural and landscape lighting for modern and dynamic illumination.
- DIY RGB LED projects requiring wireless smartphone control.
- Gaming room or TV backlighting for immersive visual ambiance.
- Bar, restaurant, and café decoration with customizable color themes.
Package Contents
- 1 x RGB LED Mobile Phone Bluetooth Controller 5-24V
