SANYO 9A0812G401 DC Fan 12V 0.38A 80x80x25mm (USED LIKE NEW)
SANYO 9A0812G401 is an 80×80×25 mm DC axial fan (12 V, 0.38 A) delivering 53 CFM airflow with ball bearing durability, ideal for efficient thermal control.
250.00 EGP
Buy NowSANYO 9A0812G401 DC Fan 12V 0.38A 80x80x25mm (USED LIKE NEW)
The SANYO 9A0812G401 is a reliable axial-type DC cooling fan, engineered for continuous operation in electronic systems and enclosures where ventilation and thermal control are essential. Although compact in its 80 × 80 mm footprint (with a 25 mm thickness), this fan delivers robust airflow, making it suited for server racks, power supplies, and other heat-sensitive devices. Its design prioritizes a balance between performance and noise, helping maintain system stability without excessive acoustic disturbance.
Constructed with quality materials and precision engineering, the 9A0812G401 features a plastic frame and impeller blades optimized for efficient air movement. The internal mechanisms, including a ball bearing, ensure long operational life under continuous load. The fan is engineered with protections such as locked-rotor and reverse polarity resistance, delivering more resilience in real-world usage. Its modest current draw (0.38 A at 12 V) allows it to integrate well with typical DC power systems without overtaxing power budgets.
As part of the SANYO “San Ace / San Cooler” 80 mm series, this fan is often employed as a replacement or upgrade in industrial, computing, or telecom equipment. Its stable performance across a reasonable temperature range makes it effective in a variety of environments. Whether cooling a densely packed PCB, venting a cabinet, or sustaining airflow in a server chassis, the 9A0812G401 helps maintain component temperatures within safe limits, contributing to longevity and reliable operation.
Features:
- Axial fan design optimized for efficient airflow.
- Ball bearing system for durability and longevity.
- Thermal protections including locked-rotor safeguard.
- Reverse polarity protection.
- Moderate acoustic level relative to performance.
- Lightweight and compact form factor.
- Stable operation across standard voltage range.
Specifications:
| Parameter | Value |
|---|---|
| Model / Part Number: | 9A0812G401 |
| Fan Type: | Axial DC Fan |
| Dimensions (L × W × H): | 80 × 80 × 25 mm |
| Rated Voltage: | 12 VDC |
| Rated Current: | 0.38 A |
| Power Consumption: | 4.56 W |
| Speed (RPM): | 4,500 RPM |
| Airflow: | 53.0 CFM (≈ 1.48 m³/min) |
| Static Pressure: | 0.323 in H₂O (≈ 80.4 Pa) |
| Noise Level: | 40 dB(A) |
| Operating Voltage Range: | 6 to 13.2 VDC |
| Operating Temperature: | –20 °C to +60 °C |
| Bearing Type: | Ball bearing |
| Color: | Black |
| Weight: | ~90 g |
Applications:
- Server / Rack Cooling.
- Power Supply Ventilation.
- Telecom / Network Equipment.
- Industrial Enclosure Cooling.
Package Contents:
- 1x SANYO 9A0812G401 DC Fan 12V 0.38A 80x80x25mm (USED LIKE NEW)
| Weight | 105 g |
|---|---|
| Dimensions | 80 × 80 × 25 mm |
