Features
- Low logic circuit power dissipation
- High current sourcing outputs (up to 25 mA)
- Latch storage of code
- Blanking input
- Lamp test provision
- Readout blanking on all illegal input combinations
- Lamp intensity modulation capability
- Time share (multiplexing) facility
- Equivalent to Motorola MC14511
Recommended Operating Conditions
DC Supply Voltage (VDD) 3V to 15V
Input Voltage (VIN) 0V to VDD
Operating Temperature Range (TA) -55°C to +125°C
