| Manufacturer | HCTL |
| Mfr. Part # | HC-TYPE-CF-24P-RAT-Z |
| Package | SMD |
| Datasheet | HC-TYPE-CF-24P-RAT-Z Datasheet |
| Description | 5A USB 3.1 1 260℃ Surface Mount 24P Female -25℃~+85℃ Gold Copper Alloy Type-C SMD USB Connectors ROHS |
Specifications
| Attribute | Value |
| Category | Connectors/USB Connectors |
| Datasheet | HC-TYPE-CF-24P-RAT-Z Datasheet |
| RoHS | |
| Current Rating – Power (Max) | 5A |
| Standard | USB 3.1 |
| Number of Ports | 1 |
| Welding Temperature (Max) | 260℃ |
| Mounting Style | Surface Mount |
| Number of Contacts | 24P |
| Gender | Female |
| Operating Temperature Range | -25℃~+85℃ |
| Contact Plating | Gold |
| Contact Material | Copper Alloy |
| Connector Type | Type-C |
