Relay Coil 5VDC Max Load 250AC 30A
These are high quality Single Pole – Double Throw (SPDT) relays. Use them to switch high voltage, and/or high current devices. This relay’s coil is rated up to 5V, with a minimum switching voltage of 5V. The contacts are rated up to 30A 250VAC or 30VDC
Specifications
| Attribute | Value |
| Category | Relays/Power Relays |
| Contact Resistance | 100mΩ |
| Release Time | 10ms |
| Operate Time | 10ms |
| Maximum Switching Voltage | 250V@AC |
| Coil Resistance | 27Ω |
| Coil Voltage | 5V |
| Maximum Switching Current | 30A |
| Contact Form | One Conversion: 1C (SPDT-Conversion) |
| Coil Rated Power | 900mW |
| Coil Type | Non-polar – Single Coil |
| Pin Number | 6 |
