Micro Switch NC NO COM Details Description
The micro switch NC NO COM means the switch has 3 terminals or 3 wires to connect with that, and different terminals have different uses in the circuit. Generally, a single pole micro switch in the circuit will wire from COM to NC or COM ON, the default connection is “COM to NC” generally.
Specifications:
| Type | a long roller lever arm |
| Operating Temperature | -40℃ to +125℃ |
| Rating | 16(5) A 125/250VAC |
| Electrical Life | 50,000 cycles Min. |
| Mechanical Life | 1000000 cycles |
| Dielectric Strength | 1000-1500VAC for 60 ± 5 sec. |
| Insulation Resistance | 100ΩM Min. |
Features:
- 3 terminals, applicable to AC DC control circuits.
- High-precision mechanism design offering acute operation.
- Durable in use.
- Designed to control the movement of a mechanical part.
- Used in industrial control applications to automatically monitor and indicate whether the travel limits of a particular device have been exceeded.
