TE Connectivity AMP Connector 8-Way 2-Row 2.54mm 280385-1

• Connector & Contact Terminates To : Printed Circuit Board
• PCB Connector Assembly Type : PCB Mount Header
• Header Type : Partially Shrouded
• Connector Shape : Rectangular
• Connector System : Board-to-Board

• Connector Contact Load Condition : Fully Loaded
• Number of Rows : 2
• Number of Positions : 16
• PCB Mount Orientation : Vertical

• Operating Voltage (VDC): 40
• Dielectric Withstanding Voltage (Max) (V): 750
• Operating Voltage (VAC): 40

• Primary Product Color : Black
• Connector Profile : Standard

• Termination Post & Tail Length : 3.5 mm
• Termination Method to PCB : Through Hole – Solder

• Connector Height : 12.6 mm 
• Centerline (Pitch) : 2.54 mm
• Row-to-Row Spacing : 2.54 mm 
• Connector Length : 22.9 mm 
• Connector Width : 7 mm 

• Circuit Application : Power & Signal

Drawing:

280385-1 Datasheet
