Terminal Block 4 Pins KF126-5.0-4P 8A 250V Green
The KF126-5.0-4P is a high-quality, 4-pin PCB mount screw terminal block designed for reliable and secure wire-to-board connections. Featuring a standard 5.0mm pitch, this compact green terminal block is perfect for a wide range of electronic projects, providing a stable connection for power and signal wiring.
Features
- Secure Connection
- Modular Design
- High-Quality Materials
- Easy Installation
- Clear Identification
Specifications
| Attribute | Value |
| Model | KF126-5.0-4P |
| Number of Pins | 4 |
| Pitch | 5.0mm |
| Color | Green |
| Rated Voltage | 250V |
| Rated Current | 8A |
| Wire Range | 26-14 AWG |
| Mounting Type | PCB Mount (Through-Hole) |
| Termination Style | Screw Terminal |
| Housing Material | PA66, UL94V-0 (Flame Retardant) |
| Contact Material | Brass (Tin Plated) |
| Screw | M2.5 |
| Operating Temp. | -40°C to +105°C |
Applications
- Power Supplies
- Industrial Controls
- Automation Systems
- LED Lighting
- Consumer Electronics
