Specifications
| Product Attribute | Attribute Value |
| Product Category: | Trimmer Resistors – Through Hole |
| Series: | 3362 |
| Termination Style: | PC Pin |
| Product: | Single Turn |
| Number of Turns: | 1 |
| Resistance: | 1 MOhms |
| Adjustment: | Top Cross |
| Power Rating: | 500 mW (1/2 W) |
| Voltage Rating: | 300 V |
| Tolerance: | 10 % |
| Temperature Coefficient: | 100 PPM / C |
| Orientation: | Vertical Adjustment |
| Minimum Operating Temperature: | – 55 C |
| Maximum Operating Temperature: | + 125 C |
| Element Type: | Cermet |
| Height: | 4.7 mm |
