UNI-T UT202+ Digital Clamp Meter
UT200+ series digital clamp meters are designed according to EN61010-2010 CAT II 600V/CAT III 300V, featuring overload protection, high reliability, high safety and high accuracy. These meters can be used to measure high-voltage frequency, temperature, AC/DC current, etc.
Features:
- True RMS
- LCD backlight
- Large screen and display digits
Specifications:
| Specifications | Range | UT202+ |
| AC current (A): | 400A | ±(2%+10) |
| AC current frequency (Hz): | 50Hz~100Hz | ±(1%+5) |
| AC voltage (V): | 600V | ±(0.8%+5) |
| AC voltage frequency(Hz): | 10Hz~10kHz | ±(1%+5) |
| DC voltage (A): | 600V | ±(0.5%+2) |
| Resistance (Ω): | 40MΩ | ±(0.8%+2) |
| Capacitance (F): | 4mF | ±(4%+5) |
| Temperature (℃): | -40℃~1000℃ | ±(1.5%+5) |
| Features | ||
| Display count: | 4000 | |
| Auto range: | √ | |
| Jaw opening: | 28mm | |
| True RMS: | √ | |
| NCV: | √ | |
| Continuity test: | √ | |
| Diode: | √ | |
| MAX/MIN: | √ | |
| Relative mode: | √ | |
| Data hold: | √ | |
| Low battery indication: | √ | |
| Auto power off: | √ | |
| General Characteristics | ||
| Power: | 1.5V battery (R03) x 2 | |
| Display: | 37mm x 25mm | |
| Product color: | Red and grey | |
| Product net weight: | UT202+：248g | |
| Product size: | 215mm x 63mm x 36mm | |
Applications:
- AC/DC Voltage Measurement.
- AC/DC Current Measurement.
- Resistance Testing.
- Capacitance Measurement.
- Frequency Analysis.
- Temperature Monitoring.
- Non-contact Voltage Detection.
- HVAC System Diagnostics.
- Electrical Maintenance and Troubleshooting.
Package Contents:
- 1x UNI-T UT202+ Digital Clamp Meter
- 1x Test Leads
- 1x Temperature Probe
- 1x User Manual
- 1x Carrying Case
