Lithium-ion Battery Charger 10S 42V 2A With GX16 3-pin Connector
The 42V 2A lithium-ion Battery Charger 10S is designed to recharge compatible 10-series (10S) lithium-ion battery packs used in electric scooters, bicycles, and other battery-powered equipment.
325.00 ج.م
متوفرالكود 8277109195124
اشترِ الآن
شحن لجميع محافظات مصريصلك حتى باب بيتك
الدفع عند الاستلامادفع عند وصول طلبك
غير متأكد أنه يناسب مشروعك؟اسألنا على واتساب - نرد بسرعة
Lithium-ion Battery Charger 10S 42V 2A With GX16 3-pin Connector
The Lithium-ion Battery Charger 10S 42V 2A is designed for charging rechargeable lithium-ion battery packs configured with 10 cells in series. A fully charged 10S lithium-ion pack typically reaches 42V, making this charger suitable for compatible 36V nominal battery systems. It provides a charging current of up to 2A, offering a practical charging solution for light electric vehicles and other portable battery-powered applications.
The charger features a GX16 3-pin connector for connecting to compatible charging ports. Its connector provides a secure physical connection when the plug type and wiring match the battery system. Before use, verify the battery chemistry, series configuration, charging voltage, connector pinout, and polarity. The battery pack should have a suitable battery management system (BMS), and the charger should only be used with battery packs specifically designed for a 42V charging voltage.
Features:
- Designed for compatible lithium-ion battery packs.
- Suitable for 10-series battery configurations.
- GX16 3-pin charging connector.
- Compact and convenient charging solution.
- Supports controlled charging of compatible battery systems.
- Suitable for electric mobility and portable power applications.
Specifications:
| Specification | Value |
|---|---|
| Input Voltage: | 100-240 V AC |
| Input Frequency: | 50/60 Hz |
| Output Voltage: | 42 VDC |
| Output Current: | 2 A |
| Maximum Output Power: | ~84 W |
| Housing Type |
GX16 3-pin Connector |
| Battery Configuration | 6S |
| Connector Cable Length | 70cm |
| Power Plug Length | 90cm |
| Adapter Dimensions | 33x55x113mm |
| LED Indicator | Yes |
| Protection Features: | Over-voltage, over-current, short-circuit |
| Typical Indicator: | LED (charging / fully charged) |
| Suitable Plug Types: | May include EU/UK/US or universal input versions |
| Cooling / Ventilation: | Natural convection (adapter housing) |
Applications:
- Electric scooters with compatible 36V lithium-ion battery packs.
- Electric bicycles using 10S lithium-ion batteries.
- Compatible portable electric vehicles.
- Rechargeable battery-powered equipment.
- Compatible 36V nominal lithium-ion battery systems.
- Battery charging and maintenance for suitable devices.
Packages Included:
- 1 × Lithium-ion Battery Charger 10S 42V 2A with GX16 3-pin connector.
- 1 × Power Cable.
| الوزن | 150 جرام |
|---|---|
| الأبعاد | 80 × 150 × 45 ميليميتر |
