Specification:
- Material: PVC
- Rated voltage: 300V
- Rated current: 25A
- Withstand voltage: AC2000V/1min
- Wire diameter: 22-12AWG
- Screw: M4, steel, gold plated
- Pitch : 9.5mm
- Number of Pin: 2
- Housing Material: PA66, UL94V-0
- Dimensions: 20mm(L) X 14.5mm(W) x 14.5(H)
- Temperature range: -40 to 105°C
- Instantaneous temperature: +250°C
Drawing:
