Linear Slide Potentiometer 20KΩ Travel Distance 20mm
A compact and reliable linear potentiometer offering precise, linear resistance adjustment over a 20 mm travel with easy PCB mounting and an ergonomic slider control.
Features
- Resistance: 20 kΩ linear taper.
- Travel Distance: 20 mm stroke.
- Form Factor: PCB-mountable through-hole design with protruding pins.
- Standard Tolerance: Typically 20% resistance tolerance.
Specifications
| Potentiometer | Slide |
| Resistance | 20KΩ |
| Power Rating | 0.1W |
| Electrical Taper | Linear |
| Element Material | Carbon |
| Termination Style | PC Pin |
| Shaft Length | 10mm |
| Travel Length | 20mm |
| Actuator Type | Lever |
| Tolerance | ±20% |
Applications
- Audio sliders and manual level controls in DIY and custom audio equipment.
- Adjustable voltage dividers for trim or calibration in test instruments.
- User interface control in compact or space-limited devices.
- Feedback or position sensing in hobbyist robotics or automation systems.
Package Contents
- 1x Linear Slide Potentiometer 20KΩ with 20mm Travel Distance.
