MRK-S Screw Connection Fused Rail Terminal Block 6mm²

MRK-S Screw Connection Fused Terminal Block 6mm²: High-Performance Circuit Protection

Features:

• Integrated Fuse Holder: Ideal for circuit protection, allowing easy fuse integration to protect circuits from overloads.
• Durable Construction: Built with high-quality PA6.6 body, copper bridge, and CK45 steel contacts to ensure durability.
• Efficient Design: 10mm cable strip length for easy wire connection and secure mounting.
• Safety Certifications: TSE/CE, UL rated for reliable performance in demanding applications.

Specifications:

• Dimensions:
  • Length (A): 60 mm
  • Width (B): 47 mm
  • Height (C): 34.5 mm
  • Mounting Length (D): 54.6 mm
  • Mounting Width (E): 8.8 mm
• Material:
  • Body: PA6.6
  • Bridge: Copper
  • Contact: CK45 Steel
  • Screw: Steel
• Voltage Rating: 750V
• Current Rating: 6.3A
• Wire Section: 6mm², 8AWG
• Temperature Range: -40°C to +140°C
• Cable Strip Length: 10 mm
• Torque: 0.8 Nm
• Safety Standards: TSE/CE, UL listed

Applications:

• Electrical Control Panels: For secure and organized wire connections.
• Power Distribution Systems: Safely distributes power with added fuse protection.
• Industrial Machinery: Ensures reliable circuit protection in heavy-duty environments.
