NIDEC D05F-24PH DC Blower Fan 24V 0.1A (USED LIKE NEW)
The Nidec GAMMA26 D05F-24PH is a high-performance 50mm centrifugal blower fan designed for precision cooling in compact spaces. Unlike standard axial fans, this blower (or “turbo”) fan pulls air in through the center and exhausts it at a 90-degree angle, creating high static pressure. This makes it ideal for ducting air through heat sinks, projectors, or narrow electronic enclosures.
✅Features
- High Static Pressure
- Double Ball Bearing System
- Reliable NIDEC Quality
- Eco-Friendly
📜📚Specifications
| Feature | Specification |
| Brand / Series | NIDEC / GAMMA26 |
| Model Number | D05F-24PH (03B) |
| Fan Type | DC Blower (Centrifugal) |
| Rated Voltage | 24V DC |
| Rated Current | 0.1A |
| Bearing Type | High-Precision Double Ball Bearing |
| Rated Speed | 5700 RPM |
| Connector | 3-Pin Interface |
| Weight | 28g |
💻Applications
- Projector Maintenance
- 3D Printing
- Inverters & Power Supplies
- Server & Networking
- DIY Electronics
🎁Package Content
- 1 x NIDEC D05F-24PH DC Blower Fan 24V 0.1A (USED LIKE NEW)
