RF N-Type Connector N-K-3-W Straight Crimp Female Jack 50 Ohm For Cable RG58/RG402/LMR195

N-Type Connector N-K-3 Straight Crimp Female Jack 50 Ohm For Cable

The RF N-Type Connector N-K-3-W is a high-quality straight crimp female jack designed for 50 Ohm coaxial cables. This connector ensures reliable and high-performance connections for various RF applications, offering ease of installation through its crimp attachment method. Its robust design makes it suitable for demanding environments requiring consistent RF and mechanical performance.

Features

• Secure Connection: Threaded coupling provides a reliable, shock- and vibration-resistant connection.
• Weatherproof Design: Suitable for outdoor and harsh environment applications.
• Easy Installation: Crimp attachment allows for fast and solderless assembly.
• High-Quality Materials: Brass body with silver plating for excellent conductivity and durability.
• Low Contact Resistance: Gold-plated center pin ensures optimal signal transfer.
• Superior Dielectric: PTFE insulator for enhanced electrical performance.
• Wide Frequency Range: Supports frequencies from DC to 11 GHz.

Specifications

Applications

• Wireless communication systems (cellular, Wi-Fi, etc.)
• Antenna connections
• Test and measurement equipment
• Military and aerospace systems
• Broadcast and television infrastructure
• RF instrumentation and analyzers
• Any 50 Ohm RF system requiring a reliable, high-frequency connection

DataSheet

• Connector N-K-3-W Straight Crimp Female-Spec-and-Data-Sheet-PDF
