7 Segment Display – Red 1.5inch Common Anode
If your looking for digital indicators and numeric displays, for your project, these 7 segment displays will be able to get the job done.
Quick Specifications:
- 1.5 inch single digit 7-segment LED displays
- Digit height: 1.5-inch (38.1mm)
- Dimensions: 44 x 30.6 x 8mm
- Emitting color: Red
- Polarity: Anode
- Made with white segments and black surface RoHS Directive-compliant
| Emitting Color | Test Condition | Wavelength(nm) | Forward Voltage(V) | Luminous Intensity (mcd) | |||
| (λp) | λ | Typ | Max | Typ | Max | ||
| Red | IF=15mA | 620-625 | 20 | 1.8 | 2.0 | 110 | 150 |
