USB Type-C DIY Connector 6Pin PD 65W Flush Mount
Round flush-mount USB Type-C 6-pin female socket supporting PD 65W power delivery, reversible insertion, for DIY panel integration and charging port replacement.
25.00 EGP
Buy NowUSB Type-C DIY Connector 6Pin PD 65W Flush Mount
The USB Type-C DIY Connector 6Pin PD 65W Flush Mount is a compact round panel-mount USB-C female connector designed for DIY electronics, custom enclosures, control panels, and embedded systems. Supporting USB Power Delivery (PD) up to 65W, it can handle power profiles up to 20V while also providing USB 2.0 data transmission through its 6-pin breakout interface. The flush-mount design allows clean installation into plastic, metal, or wooden panels, making it an excellent solution for custom charging ports and electronics projects.
Features:
- Supports USB Type-C Power Delivery (PD) up to 65W
- 6-pin breakout for easy DIY integration
- Round flush-mount design for professional installations
- Compatible with 5V–20V PD power systems
- Supports USB 2.0 high-speed data transmission
- Compact and durable construction
- Easy panel installation using locking nut
- Ideal for custom enclosures and electronic projects
Specifications:
| Parameter | Value |
|---|---|
| Product Type | USB Type-C DIY Connector |
| Connector Type | USB-Type-C Female |
| Mounting Type | Flush Mount (Round Panel Mount) |
| Interface | 6 Pin |
| Maximum Power | 65W |
| Power Delivery | USB PD |
| Supported Voltage | 5V–20V DC |
| Data Protocol | USB 2.0 |
| Data Transfer Speed | Up to 480Mbps |
| Mounting Style | Panel Mount with Locking Nut |
| Application | Charging & Data Transfer |
Pin Configuration:
Applications:
- DIY Electronics Projects
- Custom PC Cases
- 3D Printed Enclosures
- Control Panels
- Embedded Systems
- Arduino Projects
- ESP32 Projects
- Raspberry Pi Projects
- Industrial Equipment
- Battery Charging Stations
- Portable Devices
- Custom USB-C Extensions
Package Includes:
1x USB-Type-C DIY Connector 6Pin PD 65W Flush Mount.
