Panel Mount Female USB Type-C Socket Connector 2 Pin with Screw Hole (Black Board)
The USB Type-C Female Panel Mount Socket Connector is a compact Type-C interface designed primarily for power input applications. Its 2-pin configuration provides a simple positive and negative power connection rather than a full USB data interface, making it suitable for custom electronic devices, charging ports, LED equipment, embedded systems, and DIY power projects. Similar 2-pin USB-C sockets are commonly used as power-only connectors rather than for USB data communication.
The connector features a black PCB-style board and screw holes for secure mechanical mounting to a panel, enclosure, or custom project structure. The panel-mount arrangement helps reduce mechanical stress on the soldered connections and provides an accessible USB Type-C charging or power input. It is a practical choice when a compact, reversible Type-C power socket is required in custom electronic equipment.
Features:
- Female USB Type-C interface.
- 2-pin power connection.
- Panel-mount design.
- Screw-hole mounting points.
- Compact PCB construction.
- Black board design.
- Suitable for power input applications.
- Easy integration into custom enclosures and electronic projects.
- Reversible USB Type-C plug orientation.
Specifications:
| Specification | Details |
|---|---|
| Connector Type | USB Type-C Female |
| Connector Configuration | 2 Pin |
| Application | Power Input |
| Mounting Type | Panel Mount |
| Mounting Method | Screw Hole |
| Board Color | Black |
| Connector Gender | Female |
| Data Transfer | Not supported / power-only configuration |
| Construction | PCB-mounted socket |
Pinout:
| Pin Label | USB-C Function | Description |
|---|---|---|
| V | VBUS | Power Supply (5V, rated up to 5A) |
| D- | D- | USB 2.0 Data Negative |
| D+ | D+ | USB 2.0 Data Positive |
| G | GND | Ground |
| CC1 | CC1 | Configuration Channel 1 (Used for plug orientation detection and Power Delivery negotiation) |
| CC2 | CC2 | Configuration Channel 2 (Used for plug orientation detection and Power Delivery negotiation) |
Applications:
- DIY electronic projects.
- USB Type-C power input.
- Custom charging ports.
- LED lighting projects.
- Embedded electronic equipment.
- Control panels and enclosures.
- Portable electronic devices.
- Battery-powered projects.
- Robotics projects.
- Power input interfaces.
Package Includes:
- 1x USB Type-C Female Panel Mount Socket Connector 2 Pin with Screw Hole (Black Board).
