USB Type-C Female PCB Connector Right Angle TH 2P 20V
The USB Type-C Female PCB Connector Right Angle TH 2P 20V is a compact power connector designed for direct mounting on printed circuit boards. Its right-angle structure allows the USB Type-C port to be positioned at the edge of the PCB, providing convenient access for connecting compatible USB Type-C power cables.
Featuring a simple 2-pin through-hole connection, this connector is primarily intended for power applications where data transfer is not required. It provides positive power and ground connections and can be used in USB Type-C power input circuits, charging systems, and electronic devices requiring a compact external power connection.
Features:
- USB Type-C female connector.
- Right-angle orientation.
- Through-hole PCB mounting.
- 2-pin power connection.
- Supports power input applications.
- Compact design.
- Reversible USB Type-C interface.
- Easy PCB soldering.
- Suitable for PCB edge installation.
Specifications:
| Specification | Value |
|---|---|
| Connector Type | USB Type-C Female |
| Mounting Type | Through Hole |
| Orientation | Right Angle |
| Number of Pins | 2 Pins |
| Maximum Voltage | 20V DC |
| Primary Function | Power Input |
| Data Transfer | Not Supported |
| Mounting Location | PCB |
Pinout:
| Pin | Connection |
|---|---|
| 1 | VBUS (+V) |
| 2 | GND (Ground) |
Applications:
- USB Type-C power input.
- USB Type-C PD power projects.
- PCB power supply circuits.
- Charging circuits.
- DIY electronics.
- Embedded systems.
- Portable electronic devices.
- Custom PCB projects.
- Electronic repair and replacement.
Package Includes:
- 1 × USB Type-C Female PCB Connector Right Angle TH 2P 20V.
