BTB04-600 Triac 600V 4A Through Hole TO-220
8.00 ج.م
متوفرالكود 3496300094608
اشترِ الآن
شحن لجميع محافظات مصريصلك حتى باب بيتك
الدفع عند الاستلامادفع عند وصول طلبك
غير متأكد أنه يناسب مشروعك؟اسألنا على واتساب - نرد بسرعة
Features:
A gate current capability sensitivity of 10mA.
Pin Configuration:
Specifications:
| Product Attribute | Attribute Value |
| Datasheet | BTB04-600 |
| Product Category: | Triacs |
| Model | BTB04-600 |
| Package/Case | TO-220 |
| Mounting Type | Through Hole |
| Number of terminals | 3 |
| Non Repetitive On-State Current | 38 A |
| Rated Repetitive Off-State Voltage VDRM | 600 V |
| Current Rating | 4 A |
| Off-State Leakage Current @ VDRM IDRM | 5 µA |
| On-State Voltage | 1.5 V |
| Holding Current Ih Max | 15 mA |
| Gate Trigger Voltage – Vgt | 1.3 V |
| Gate Trigger Current – Igt | 25 mA |
| Operating Temperature | -40°C ~ 125°C |
Applications:
Where high surge current capability is required, such as lighting, corded power tools and industrial.
Datasheet
