UNI-T UT171B Industrial True RMS Digital Multimeters
The UNI-T UT171B Industrial True RMS Digital Multimeter is designed for accurate electrical measurements, industrial equipment troubleshooting, electronic circuit testing, and professional maintenance.
14,000.00 ج.م
متوفرالكود 3496300161348
اشترِ الآن
شحن لجميع محافظات مصريصلك حتى باب بيتك
الدفع عند الاستلامادفع عند وصول طلبك
غير متأكد أنه يناسب مشروعك؟اسألنا على واتساب - نرد بسرعة
UNI-T UT171B Industrial True RMS Digital Multimeters
The UNI-T UT171B is a professional handheld digital multimeter designed for industrial electrical testing, electronics servicing, and maintenance applications. It measures AC and DC voltage and current, resistance, capacitance, frequency, and temperature. Its True RMS measurement capability supports accurate AC measurements, while its high-resolution digital display provides detailed readings for technicians and engineers working with electrical systems, automation equipment, and electronic circuits.
The UT171B also supports data recording, peak hold, non-contact voltage detection, low-impedance voltage measurement, and USB communication for transferring measurement data to a computer. Its rechargeable battery, protective measurement functions, and portable design make it suitable for workshops, industrial facilities, laboratories, and field service. Always follow the manufacturer’s operating instructions and safety ratings when measuring high-voltage circuits or electrical equipment.
Features:
- AC+DC measurement.
- Peak hold.
- Rechargeable battery.
- VFC low-pass filtering.
- USB/Bluetooth communication.
Specifications:
| Specifications | Range | UT171B | UT171C |
| DC voltage (V) | 1000V | ±(0.025%+5) | ±(0.025%+5) |
| AC voltage (V) | 1000V | ±(0.4%+40) | ±(0.4%+40) |
| DC current (A) | 10A | ±(0.15%＋2) | ±(0.15%＋2) |
| AC current (A) | 10A | ±(0.75%＋5) | ±(0.75%＋5) |
| Resistance (Ω) | 40MΩ | ||
| 60MΩ | ±(0.05%＋2) | ±(0.05%＋2) | |
| Admittance (nS) | 60nS | ±(1%＋10) | ±(1%＋10) |
| Capacitance (F) | 40mF | ||
| 60mF | ±(2.5%+40) | ±(2.5%+40) | |
| Frequency (Hz) | 10Hz~10MHz | ±(0.01%+5) | ±(0.01%+5) |
| Temperature (°C) | -40°C~1000°C | ±(1%+30) | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+50) | ±(1.5%+50) |
| Features | |||
| Display count | 60000 | 60000 | |
| Auto/Manual range | √ | √ | |
| True RMS | √ | ||
| Bandwidth (Hz) | 100kHz | √ | √ |
| 4~20mA loop | 0~100% | √ | √ |
| LoZ (ACV) | Around 3kΩ | √ | √ |
| Diode | Around 3V | √ | √ |
| Continuity buzzer | √ | √ | |
| Duty cycle | 0.1%~99.9% | √ | √ |
| NCV/Data hold/MAX/MIN | √ | √ | |
| Relative mode | √ | √ | |
| Data storage | 9999 | 9999 | |
| Display type | EBTN | OLED | |
| Analog bar graph | 31 | 31 | |
| LCD backlight | √ | √ | |
| Mis-plug alarm | √ | √ | |
| Low battery indication | √ | √ | |
| Auto power off | √ | √ | |
| Input protection | √ | √ | |
| Input impedance for DCV | √ | √ | |
| Input impedance for DCV | Around 1GΩ | √ | √ |
| General Characteristics | |||
| Power | 7.4V 2000mAh Li-ion battery | ||
| Display | 70.6mm x 35.3mm | ||
| Product color | Red and grey | ||
| Product net weight | 384g | ||
| Product size | 206mm x 95mm x 55mm | ||
| Standard accessories | Batteries, test leads, point contact temperature probe, USB interface cable, power adaptor (UT171B/C), PC software CD |
||
| Standard individual packing | Gift box, carrying bag, English manual | ||
| Standard quantity per carton | 5pcs | ||
| Standard carton measurement | 390mm x 310mm x 205mm (0.55CBM per standard carton) | ||
| Standard carton gross weight | 5.6kg | ||
| Optional accessory | Bluetooth adaptor (UT-D07) | ||
Applications:
- Industrial electrical maintenance and troubleshooting.
- Factory automation and control system testing.
- AC and DC voltage measurements.
- Current measurements in electrical circuits.
- Electronic component testing and repair.
- Resistance, capacitance, and frequency measurements.
- Temperature measurement using a compatible probe.
- Variable-frequency drive and motor-control diagnostics.
- Electrical panel inspection and servicing.
- Laboratory testing and technical education.
- Recording and analyzing measurement data on a computer.
Package Includes:
- 1 × UNI-T UT171B Industrial Digital Multimeter.
